Product Description
Output Amplitude Limits
1 Mil Load (or greater) 40μV to 200 V
50 9 Load 40μV to 5 V
Accuracy ± 0.25%, ± 1 μV
Aberrations Less than ± 15% of amplitude t 10 mV.,anDuration.-<5% of period or 2us whichever is greater. Measured from 50% point of transition.
Settling Time 40μV to 10 V<2 μs to.25% accuracy.12 V to 200 V<15 μs to.25% accuracy.Variable Range±9 .9%
Frequency
40μV to 80 mV 10 Hz to 10 kHz Frequency selected in decade steps.
100 mV to 10 V
10 Hz to 100 kHz, or DC
12 V to 200 V
10 Hz to 10 kHz, or DC
Polarity Positive
Source Resistance 50 S2
Current Limit 40 μV to 5 V 100 mA Minimum Checked for 5 V across a 50 S2 load.
12 V to 200 V
10 mA Minimum
Checked for 100 V across a 10 k!2
load.
Short Circuit Current 40μV to 10 V Less than 200 mA
12 V to 200 V Less than 30 mA
