Product Description
*Brand New* Vishay - BC Components 101 PHR-ST Aluminum Capacitors
Power High Ripple Current Screw Terminals
- 33,000 uf (µf)
- 36V
- D x L = 50mm x 105mm
- Standard M5 disc screw terminal
FEATURES
- Polarized aluminum electrolytic capacitors, non-solid electrolyte
- Large types, cylindrical aluminum case, insulated with a blue sleeve
- Pressure relief in the sealing
- Long useful life
- Compliant to RoHS directive 2002/95/EC
APPLICATIONS
- Buffering and Filtering
- Motor Drives, Inverters, UPS (Uninteruptible Power Supplies) and Traction Systems
- Pulsed Power Supplies
Rated capacitance at 100 Hz, tolerance ± 20 % = 33,000µF
Rated RMS ripple current at 100 Hz, 85 °C = 12.9A
Maximum equivalent series resistance at 100 Hz = 14mΩ
Maximum impedance at 20 kHz = 12mΩ
