HP 8902A / Agilent 8902A Measuring Receiver OPT 003, 021, 030, 033, 037

The Agilent HP 8902A measuring receiver delivers the accuracy and resolution of a high performance power meter at frequencies from 150 kHz to 1.3 GHz (50 MHz to 26.5 GHz with the Agilent 11793A microwave converter) and levels from +30 dBm to 127 dBm. It accurately measures AM, FM, and fM, including residuals and incidentals, with a single keystroke. The 8902A measuring receiver, with the 11793A (not included), counts RF signals to 26.5 GHz with 10 Hz resolution and excellent longterm frequency stability.

Option included:

• Option 003- RF Connectors on Rear Panel Only
• Option 030- High Selectivity
• Option 033- 25.0 kHz Filter
• Option 037- Carrier Noise Filter
• Option 021 - Deletes the 3.5 mm to N-type adapter
