Product Description
Rated load voltage 24 VDC
Overvoltage protection no
Protection with automatic circuit breakers yes, tripping characteristic B, C
Max. current-carrying capacity (up to 60° C) 10 A
Short-circuit protection no
Galvanic isolation
Between rated load voltage and backplane bus Yes
Between the power modules Yes
Insulation test voltage 500 VDC
Current consumption
From the load voltage L+ (no load) max. 4 mA
Power dissipation of the module typ. 100 mW
Parameter length 3 bytes
Status, interrupts, diagnostics
Diagnostic function Yes
General fault
Load voltage monitoring
Red "SF" LED
Green "PWR" LED
