This Portable Satellite News Gathering ( SNG ) antenna has three interchangeable feeds, which include orthogonal linear, orthogonal circular, and three port types. This antenna utilizes a three panel offset reflector of a sandwich construction, a tetrahedral mount which  doubles as a transit frame, and a feed system transit case.The antenna can provide VSAT data as well as video services and has a high antenna gain.

MODEL A096S-117140 / 9006-800 ANTENNA SPECIFICATIONS

Frequency:

• 10.95-12.75GHz - Receive
• 14.0-14.5 - Transmit

Polarization:

• Manually Adjustable Orthogonal Linear

Gain:

• 47.5 dBi at 12.0 GHz
• 48.9 dBi at 14.25 GHz

VSWR ( goal ):

• 1.3, (maximum)

Isolation:

• 40  Dbi ( Minimum)

Cross Polarization:

• 30 dB, (minimum)

Power Handling:

• 750 Watts CW, ( Maximum )

RF Ports:

• WR-75 waveguide flanges ( 2)

Size:

• Offset, 2.4M
