Product Description
- FEATURES:
- System-compatible universal signal source
- Frequency increments 10/50/100 Hz
- Modulation generator with fixed frequencies 0.4/1/3/15 kHz
- Non-Volatile memory for 40 instrument setups b>
SPECIFICATIONS: - Frequency Range: 100 kHz to 1 GHz
- Resolution: f <250 MHz - <25 Hz f > 250 MHz - <100 Hz
- Reference Frequency with SMX-B1 option: 10 MHz Aging after 20 days <1 x 10-9/day
- Spectral Purity Spurious Signals: Harmonics <-30 dBc (for level < 10 dBm) Residual AM rms (0.03 to 20 kHz) - <0/02%
- OPT SMX-B1 826.9519.02 OXCO Reference Oscillator & IEEE488
Complete specifications available upon request."
