Product Description
Microwave Filter 3329-42/42(1000) Common Cable Headend Bandsplitter
A bandsplitter separates a frequency spectrum into a low band and a high band. It can also be used to combine these high and low bands to a common output.
Splitters are AC/DC passing on the low band side only.
Passband (MHz)
High: 5-42
Low: 54-1000
Insertion loss (max): 3.0dB
Mutual Isolation (min): 30dB
Mechanical Specifications:
Baseplate Dimensions: 4" x 1.5"
Baseplate Dimensions: 6.125" x 2.25"
Connectors: 75 ohm - Type "F
