PROTEUS 8000 SERIES SPECIFICATIONS

•  Flow ranges from 0.2 to 227 LPM / 0.05 to 60 GPM
•  Accuracy of 3% of flow range
•  Liquid temperatures from -40 to 90°C can be monitored at up to 30°C ambient temperature without remote-mounting the electronics!
• Enhanced accuracy and stability from digital signal processing
• 15 alarm values selectable in 5% steps–plus AutoAlarm!
• Standard 0–10 VDC or 0–5 VDC, and 4–20 mA outputs
• Specialized calibration to account for viscosity effects of fluid and operating temperature
• Bright tricolor LED provides clear visual indication of flow status
• NEMA 4X / IP66 packaging ensures reliable
  performance in wet environments

Proteus 8000 Series instruments provide accurate, rugged, reliable and cost effective measurement of heat transfer fluids and other liquids from -40 to 90°C. A built in relay can be used to sound an alarm or shut down a system before damage is done to valuable equipment and products.
