    ABB AF750-30-11 100-250V 50/60Hz / 100-250V DC Block Contactor

    Double click on above image to view full picture

    More Views

    • ABB AF750-30-11 100-250V 50/60Hz / 100-250V DC Block Contactor

    ABB AF750-30-11 / 1SFL637001R7011 AC/ DC Block Contactor 1050A 1000V, with CAL18-11

    Part Number: sku8564
    Add Items to Cart
    Quantity in Stock: 2

    Ask a Question

    Product Description

    ABB AF750-30-11  AF750 Series DC Block Contactor 1050A 1000V

    This is a 3-phase contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 1000 V. Operated with wide control voltage range 100-250 V, AC/DC.

    AF750 Series of contactors are mainly used for controlling 3-phase motors and power circuits up to 1000 V AC or 850 V DC (Up to 850 V DC for AF750). These contactors are of the block type design with 3 main poles.

    • control circuit: AC or DC operated with electronic coil interface accepting a wide control voltage range
    • (e.g. 100...250 V AC and DC), only 4 coils to cover control voltages between 48...500 V 50/60 Hz and
    • 24...500 V DC
    • can manage large control voltage variations
    • reduced panel energy consumption
    • very distinct closing and opening
    • can withstand short voltage dips and voltages sags (SEMI F47 conditions of use on request).
    • built-in surge suppression

    Type = AF750-30-11
    Order Code = 1SFL637001R7011

    AC / DC Operated with 1 N.O + 1 N.C. auxiliary contacts

    IEC Rated Operational Power 400V AC-3 = 400 kW
    IEC Rated Operational Current 0<40ÂșC, 690V AC-1 = 1050 Amps
    UL/CSA 3-phase Motor Rating 480V = 600 HP
    UL/CSA General use rating 600V AC = 900 Amps
    Rated Control Circuit Voltage Uc min...Uc max = 100...250 V 50/60 Hz / 100...250 V DC
    Auxiliary Contacts Fitted = 1 NO, 1 NC

    Includes: 1 x CAL18-11 2-Pole Auxiliary Contact Block, Pilot Duty A600, Q300

    Note: the contactor has some marks from being moved around the warehouse, but has not been used.
