Product Description
Takes 400 Hz signals from a synchro and converts that information to a BCD digital output.
- FEATURES:
- Standard Low Profile Converters with Optional Velocity Output
- Signal and Reference Input: Internal Transformer Isolation All Common L-L Levels and Frequencies
- Accuracy: 12 Bit: 8.5 Minutes
- Logic: TTL Compatible Parallel Binary Angle Output
- Power Required: +15 VDC and +5 VDC
SPECIFICATIONS: - Input SDC: Synchro
- Resolution 632: 12 bits
- Signal Input Voltage and Frequency H: 90 VL-L 400 Hz (synchro or resolver)
- Temperature Range 3: 0oC to +70oC
- Package: Module (2.625 x 3.125 x 25/32 inches)
Specifications available upon request."
