Sensing method     Through-beam
Sensing distance     0 m to 10 m
Standard sensing object     Opaque: 12 mm dia. Min.
Directional angle     Emitter:3 to 15 DEG
Receiver:3 to 15 DEG
Light source     Red LED (660nm)
Power supply voltage     12 to 24 VDC -10% to 10% (ripple(p-p) :10% Max.)
Current consumption     Emitter: 15mA DC Max., Receiver: 20mA DC Max.
Control output (Output type)     PNP open collector output
Control output (Load current)     0 to 100 mA
Control output (Residual voltage)     (DC) 1 V Max. (Load current: Less than 10mA)
(DC) 2 V Max. (Load current: 10 to 100 mA)
Operation mode     Light-ON/Dark-ON selectable
Load power supply voltage     26.4 VDC Max.
Protective circuit     Surge suppressor
Output short-cut protection
Output reverse polarity protection
Power supply reverse polarity protection
Response time     1 ms Max.
Sensitivity setting     Single-turn adjustment
Ambient illuminance     Incandescent lamp:3000 lux Max., Sunlight:10000 lux Max.
Ambient temperature     Operating: -25 to 55 CEL
Storage: -40 to 70 CEL(with no icing or condensation)
Ambient humidity     Operating: 35 to 85 %RH
Storage: 35 to 95 %RH(with no condensation)
Insulation resistance     20 M OHM Min. at 500 VDC between charged parts and the case
Dielectric strength     1000 VAC at 50/60 Hz for 1 minute between charged parts and the case
Vibration resistance     10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Shock resistance     500m/s2 for 3 times each in X, Y, and Z directions
Degree of protection     IEC60529: IP67
Applicable standard (EC Directive (Low Voltage Directive))     EN60947-5-2
Applicable standard (EC Directive (EMC Directive))     EMI: EN60947-5-2
Emission Enclosure: EN55011 Group 1 class A
EMS: EN60947-5-2
Immunity ESD: IEC61000-4-2
Immunity RF-interference: IEC61000-4-3
Immunity Burst: IEC61000-4-4
CE marking: Equipped
Connection method     M8 connector models
Indicator     Operation indicator(orange), Stability indicator(green), Power indicator(orange)
