Sensing method     Diffuse-reflective
Sensing distance     0 mm to 300 mm (White paper 100*100mm)
Differential distance     20% Max. of sensing distance
Light source     Infrared LED (950nm)
Power supply voltage     12 to 24 VDC -10% to 10% (ripple(p-p) :10% Max.)
Current consumption     40mA DC Max.
Control output (Output type)     PNP open collector output
Control output (Load current)     0 to 100 mA
Control output (Residual voltage)     (DC) 2 V Max. (Load current 100mA Max.)
Operation mode     Light-ON/Dark-ON selectable
Protective circuit     Surge suppressor
Output short-cut protection
Power supply reverse polarity protection
Mutual interference prevention
Response time     1 ms Max.
Sensitivity setting     Single-turn adjustment
Ambient illuminance     Incandescent lamp:3000 lux Max., Sunlight:10000 lux Max.
Ambient temperature     Operating: -25 to 55 CEL
Storage: -40 to 70 CEL (with no icing or condensation)
Ambient humidity     Operating: 35 to 85 %RH
Storage: 35 to 95 %RH (with no condensation)
