FEATURES:

E3X-A41 and E3X-A51

• Supply voltage: 10-30 VDC
• Output: PNP
• Operation mode: Light-ON Dark-ON or SET modes (switch selectable)
• Sensitivity: 8-turn potentiometer with clutch and indicator
• Circuit protection: Output short circuit protection. DC power reverse polarity protection
• Indicators: Light received (red LED) and output stability (green LED)

  E3X-A51 only
• Alarm output 50 mA 30 VDC max.
• Self-diagnostic function Provided
• Off-delay timer Provided

  E3X-A41 40pcs: $ 70.00 US ea.
  E3X-A41-M1J 1unit $ 75.00 US

  E3X-A51 11pcs: $ 80.00 US ea

  E3X-NH41
• Ideal for detecting small objects or fine wires
• Output: PNP
• Supply voltage: 12 - 24 VDC
• Circuit protection: Output short-circuit protection reverse polarity on supply
• Operation modes: Light ON and Dark ON switch-selectable
• The E3X-NH Employs a 16-Bit Processor
• An Automatic Sensitivity Adjustment allows stable detection of objects in a frequently changing environment
• Three teach modes are available
• 8-point scaled sensitivity meter clearly displays a targets reflectivity level
• A manual fine tuning sensitivity feature allows 13 threshold adjustments using an easy-to-read digital scale

  E3X-NH41 : 7pcs: $ 90.00 US ea


Fiber Optic Cables Available:


E32-DC200

• 15pcs
• Approx. 2.5ft
• 4 with flexible stainless sheaths (bottom left photo)
• $25.00 US ea + $10.00 US for sheathed cable
  E32-TC200
• 10 pcs
• Approx. 3ft
• $25.00 US ea
  E32-D24
• 2 x 22" $ 60.00 US ea
• 2 x 29" $ 65.00 US ea
• 1 x 80" $ 75.00 US ea
  E32-DC200E
• 4 x 16" $35.00 US ea
• 5 x 6ft $50.00 US ea
  E32-DC200C
• 4pcs
• $35
  E32-DC200F
• 1 unit
• $ 65.00 US
  E32-CC200
• 3pcs
• $ 30.00 US ea
  E32-T16
• 1 set 2pcs
• $ 60.00 US ea

Data Sheets available upon request.
