Product Description
The National Instruments PXI-8105 is a high-performance Intel Core Duo
T2500-based embedded controller for use in PXI and CompactPCI systems.
With its 2.0 GHz dual-core processor and dual-channel 667 MHz DDR2
memory, the NI PXI-8105 is ideal for applications requiring intensive
analysis or system development. A PXI-8105 embedded controller in a
PXI chassis offers a compact, high-performance PC platform for modular
instrumentation and data acquisition applications
CPU Intel Core Duo Processor T2500
(2.0 GHz Dual Core)
Front-side bus 667 MHz
L2 cache 2048 KB
Dual-channel 667 MHz DDR2 RAM, standard 512 MB (1 x 512 MB)
Dual-channel 667 MHz DDR2 RAM, maximum 4 GB (2 x 2 GB)
Hard drive, minimum 60 GB SATA1
10/100/1000 BASE-TX Ethernet 3
GPIB (IEEE 488) controller 3
Serial port (RS232) 3
Parallel port 3
Hi-Speed USB ports 4
ExpressCard/34 slot 3
PS/2 keyboard/mouse connector _2
Watchdog/trigger SMB 3
Installed OS Windows XP
