Product Description
- SPECIFICATIONS:
- Frequency Range: 10 kHz to 1 GHz
- Displayed Resolution: 10 Hz up to 100 MHz / 100 Hz above 100 MHz
- Frequency Response: ±0.5 dB from 50 Hz to 50 kHz relative to 1 kHz, using external modulation
- Display: 7 Digit LCD
- Distortion: <2% Total Harmonic distortion at 1 kHz modulation and max deviation for any carrier above 250 kHz
- RF Output Level Range: -127 to +13 dBm (0.1 µV to 1 V PD)
- Output Impedance: 50 ohms
- VSWR: <1.5:1 for output levels below -7 dBm
