Branson L-1 Series linear vibration welders are complete plastics assembly systems designed to weld large or irregularly-shaped thermoplastic parts. The Model VW/4L-1 will handle parts up to 33.5 inches longby 18 inches wide (851 x 457 mm) or multiple smaller parts.
The VW/4L-1 has a 15 Hp adjustable digital power supply with nominal vibrating frequency of 240 Hz. Modular construction also allows the individual components (vibrator assembly and power supply/ control panel) to be adapted to automated or custom systems

New L-1 Series features include:
• Improved ergonomics table height lowered to 35" and door opening increased providing easier access for part loading and unloading.
• Touch screen operator interface provides easy access to all operating parameters
• Hydraulic lift/clamp system
• Sound level reduced to 82 dBA* (time weighted average)
• Increased power
• Weld-by-distance option
• Power Requirements: 480 VAC 3 Phase 60 Hz
• Current Rating: Full Load 18 Amps / Amp Rating of Largest Load 13 Amps / Max Short Circuit Interrupting Cap 10 000 Amps

Complete specifications available upon request."
