• Sensing Distance : 200mm
• Differential Travel: 20% max of sensing distance
• Power Supply Voltage : 10 to 30 VDC, including ripple ( p-p) 10%
• Current Consumption: 35mA max
• Response Time: Operation or reset 0.5 ms max
• Ambient Temperature: Operating- -25°C to 55°  ( With no icing or condensation )

                                                         Storage - - -40° C to 70°C  ( with no icing or condensation )

• Ambient Illumination:  Incandescent lamp 5,000 lx max ...Sunlight 10,000 lx max
• Ambient Humidity : Operating 35% to 85% ( with no condensation )

                                                  Storage 35% to 95% ( with no condensation)

• Insulation Resistance: 20 M ohm min at 500 VDC between current carrying parts and case.
• Dielectric Strength : 1,000 VAC 50/60 Hz for 1 min between current carrying parts and case.
• Vibration distance : 10 to 55 Hz, 1.5-mm double amplitude for two hours each in X, Y and Z directions.
• Shock Resistance : Destruction 500m/s2, 3 times each in X, Y, And Z directions.
•
