SENSING RANGE :

• 5 TO 50mm

SETTING RANGE:

• 30 TO 50 mm

DIFFERENTIAL TRAVEL :

• 4% Max . of setting distance

REFLECTIVE CHARACTERISTICS

• 4%max. of Setting Distance

LIGHT SOURCE:

• Red LED ( 670 nm )

SPOT SIZE

• 1-mm dia. max. ( at 38-mm sensing distance )

POWER SUPPLY VOLTAGE :

• 10 TO 30 VDC including 10% (p-p) ripple

CURRENT CONSUMPTION:

• 55mA max.

CONTROL OUTPUT:

• Load Power Supply Voltage-30VDC
• Load Current - 100mA max.
• Residual Voltage: NPN output : 1.2 V max., PNP output 2.0V max.
• Open Collector output ( NPN / PNP , depends on model )
• Light ON / Dark ON selectable

PROTECTION CIRCUIT:

• Power supply reverse polarity protection,
• Load short circuit protection
• Mutual interference prevention

RESPONSE TIME:

• Operate or reset: 1.5 ms max.

DISTANCE SETTING:

• Teaching ( In NORMAL or ZONE mode )

AMBIENT ILLUMINATION:

• Incandescent Lamp 3,000 lx max.
• Sunlight; 10,000 lx max.

AMBIENT TEMPERATURE:

• Operating -25°C to +55°C
• Storage -30°C to 70°C ( with no icing or condensation )

AMBIENT HUMIDITY:

• Operating 35% to 85%
• Storage 35% to 95% ( with no condensation )

INSULATION RESISTANCE :

• 20 MΩ min. at 500VDC

DIELECTRIC STRENGTH:

• 1,000VAC, 50/60Hz
