Product Description
The 59501A is an isolated digital-to-analog converter designed to provide a convenient interface between the HP interface BUS and those HP power supplies that are not equipped with built-in HP-IB, but are capable of being analog voltage-controlled.
- DC Output Mode: Unipolar 0 to 9.99 V (low range 0 to 9.999 V)
- DC Output Mode: Bipolar -10 to +9.98 V (low range -1 to +0.998 V)
- DC Output Current: 10 mA maximum
- Resolution: Unipolar 10 mV (low range 1 mV)
- Resolution: Bipolar 20 mV (low range 2 mV)
"
