Product Description
Specifications:
- Frequency Range: 10 MHz to 18 GHz
- Excess Noise Ratio ENR Range (0-55C): 14-16dB
- SWR: 0.01-0.03 GHz <1.3:1 / 0.03-5.0 GHz <1.15:1 / 5.0-18.0 GHz <1.25:1
- Reflection Coeficient (Rho) r: 0.01-0.03 GHz = 0.13 / 0.03-5.0 GHz = 0.07 / 5.0-18.0 GHz = 0.11
- Impedance: 50 ohm nominal
- Reverse Power (max): 1 Warr
- Power Required: 28 ± 1V, 60 mA peak, 30 mA avg for source ON
- Connectors: Output = APC-3.5 (male) / Input = ians BNC (f)
