Product Description
The FE7A Series units are self contained and require no separate amplifier for signal conditioning. Each control contains its own infrared light source, photodiode, amplifier circuitry power supply, signal strength/alignment indicator, and output transistor. The FE7A Series operates on a broad range DC Voltage from 10 to 28 VDC.
SPECIFICATIONS
Scan Type : Diffuse Scan
Scanning Distance : 2.75 Inches ( 7cm )
Power Dissipation : 20mA max
Rate of Operation : 250Hz maz ( On/Off time 2 ms Max )
Humidity Range : 85% RH
Sealing : IP64( dust proof, splash proof ) and NEMA 12
