Product Description
- SPECIFICATIONS
- Frequency Range: 2 (1.8) to 30 MHz continuous
- Tube: One Eimac 4CX15000A
- Power Output (max.): 15 KW into 50 ohms
- Drive Power: 1200W for full output
- Power Supply: 208 V 3 phase
- Heat Dissipation: 18KW at 10 KW CW
- Ambient Operating Temp.: 0°C / 32°F to 50°C / 122°F
- Acoustic Noise: 60 db
- Humidity: 0 - 95% relative humidity
- Weight(approx.): 1600 lbs / 726 kg
- Measures: 79 x 32 x 40" / 200 x 81 x 101 cm
"
