Product Description
Compact, modulated, self-contained convergent mode sensor for 24-240V ac operation
Produces a precise 1.3 mm (0.05 in) diameter sensing spot at a focus point 16 mm (0.65 in) from the lens surface
Switch-selectable for light operate or dark operate
SPST SCR solid-state output switches up to 300mA; low leakage current and saturation voltage
Rugged, epoxy-encapsulated construction: meets NEMA standards 1, 2, 3, 3S, 4, 4X, 12 and 13; IEC IP67
Physically and electrically interchangeable with 18 mm barrel-type photoelectrics
Visible Red 650 nm Convergent, Focal Point: 16 mm
