SPECIFICATIONS:


• Output Ratings:
  Adjustable from 0 to 60V and 0 to 50A.  Maximum output power is 1000W at 50A, 1050 W at 60V, and approximately 1200 W at mid-range
  Range 1: 0 to 60 V 0 to 17.5 A
  Range 2: 0 to 40 V 0 to 30.0 A
  Range 3: 0 to 20 V 0 to 50.0 A
  Power (max.): 1200 W
• Ripple & Noise from 20 Hz to 20 MHz:
  Voltage rms: 8 mV
  Peak-to-Peak: 40 mV
• Load Regulation:
  0.01% + 5 mV

• Input two internal switches and two internal jumpers permit operation from 120 VAC, 24 A max / 220 VAC, 15 A max or 240 VAC 14 A max (AC -13%, +6%), 48-63 Hz, single phase

OPT 002- provides extra programming and monitoring capabilities for system use. A card inserted into the power supply is accessible through a 37-pin connector on the rear panel. It provides easy access to the control and monitor signals available on standard units, as well as these additional features:

• OVP trip and reset
• power supply inhibit

Additional Specs available upon request.

Additional specifications available upon request
