Product Description
Advantest R3361B Spectrum Analyzer w/ Internal Tracking Generator 9 kHz to 3.6 GHz
Specifications:
Inrernal Tracking Generator: Standard
Frequency Range: 9 kHz - 3.6 GHz
Input Impedance: 50 ohm
Dynamic Range, Average Noise Level: -120 dBm +1.55 f (GHz) dB
Frequency Response: <+0.5 dB 100 Hz to 2 GHz / <+1.0 dB 9 kHz to 2.6 GHz
Resolution: 3 dB bandwidth: 30 Hz - 1 MHz switchable in 1-3 steps / 6 dB 200 Hzm 9 kHz, 120 kHz
GPIB
Input Impedance: 50 ohm
Dynamic Range, Average Noise Level: -120 dBm +1.55 f (GHz) dB
Frequency Response: <+0.5 dB 100 Hz to 2 GHz / <+1.0 dB 9 kHz to 2.6 GHz
Resolution: 3 dB bandwidth: 30 Hz - 1 MHz switchable in 1-3 steps / 6 dB 200 Hzm 9 kHz, 120 kHz
GPIB
Additional specifiations available upon request.
