The Galil DMC 1840 is a 48-bit parallel digital input/output card designed for use in PCI-Bus computers. The card is 6.9 inches (175 mm) long and may be installed in any 5-volt PCI slot in IBM and compatible computers. 48S cards use 50-pin headers on the face of the board.

• Accepts up to 12 MHz encoder frequencies for servos and outputs pulses up to 3 MHz for steppers
• PID compensation with velocity and acceleration feedforward, integration limits, notch filter and low-pass filter.
• Modes of motion include jogging, point-to-point positioning, contouring, linear and circular interpolation, electronic gearing and ECAM
• Multitasking for concurrent execution of up to eight application programs
• Non-volatile memory for application programs, variables and arrays
• Dual encoders, home input and forward and reverse limits accepted for every axis
• 8 Uncommitted inputs and 8 outputs for 1- through 4-axes models, 16 inputs and 16 outputs for 5- through 8-axis models
• Expansion for 64 I/O with optional DB-14064
• 8 uncomitted analog inputs
• High speed position latch and output compare
• 2nd FIFO for instant access to status and parameters
• High-density shielded cables and optical isolation for noise immunity.
• Connects directly to AMP-19540 4-axis drive for cost-effective, multi-axis controller/drive solution. Drives brush or brushless servos up to 500 Watts each. Or, connect to external drives of any power range using ICM-2900 interconnect module
• Communication drivers for Windows, QNX, and Linux
