ElectroCraft DEK S663-1A/8+100LD+Conns, Model 3, P/N 43-0968 Made by Dunkermotoren GR 80X40 88710 05239 Brushed DC Servo Motor, 40V BNIB / NOS
sku113101 — low stock
$650.00CAD
By DEK
<p> SPECIFICATIONS</p><p>Rated Voltage: 40VDC</p><p>Nominal Speed: 3500RPM</p><p>Nominal Torque: 35Ncm</p><p>Friction Torque at no load: 4Ncm</p><p>Peak stall torque: 406Ncm</p><p>Maximum Torque: 341Ncm</p><p>No Load Speed: 3450RPM</p><p>No Load Current: 0.32A</p><p>Demagnetisation Current: 32A…
Description
<p> SPECIFICATIONS</p><p>Rated Voltage: 40VDC</p><p>Nominal Speed: 3500RPM</p><p>Nominal Torque: 35Ncm</p><p>Friction Torque at no load: 4Ncm</p><p>Peak stall torque: 406Ncm</p><p>Maximum Torque: 341Ncm</p><p>No Load Speed: 3450RPM</p><p>No Load Current: 0.32A</p><p>Demagnetisation Current: 32A</p><p>Weight Of Motor: 2800G</p><p>DEK 16076</p><p> </p><p> </p>
