Edmund Optics / Basler acA2000-165umNIR USB3.0 Monochrome Camera

Description

Video Output: USB 3.0 Rev: 29 Type: Monochrome Camera Manufacturer: Basler Mounting Threads: ¼-20 with Tripod Mount Adapter Image Buffer: Not Specified Camera Family: ace Model Number: acA2000-165um Imaging Sensor: CMOSIS CMV2000 Type of Sensor: Progressive Scan CMOS Type of Shutter: Global Camera Sensor Format: 2/3" Resolution (MegaPixels): 2.20 Pixels (H x V): 2,048 x 1,088 Pixel Size, H x V (μm): 5.5 x 5.5 Sensing Area, H x V (mm): 11.26 x 5.98 Frame Rate (fps): 165.00 Pixel Depth: 10/12 bit Exposure Time: Freely Programmable Connector: USB 3.0, Micro-B with Screw Locks Power Supply: Power over USB Power Consumption (W): 3.2 GPIOs: 1 opto-coupled input line, 1 opto-coupled output line, 2 general purpose I/O (GPIO) lines Synchronization: Hardware Trigger (GPIO) or Free-Run Dimensions (mm): 29.3 x 29 x 29 (excludes connectors and lens mount) Weight (g): 80 Mount: C-Mount Housing: Full Interface Port Orientation: Back Panel Dynamic Range (dB): 56.5 Operating Temperature (°C): 0 to +50 Storage Temperature (°C): -20 to +80 GPIO Connector Type: 6-pin Hirose (HR10) Machine Vision Standard: USB3 Vision v1.0 Operating System: Software Driver: Windows 32 and 64 bit, Linux, OS X

Specifications
