Ailtech Singer Gertsch / Tegam / Eaton DSRB-5CD-4R Decade Synchro / Resolver Bridge R/S Input 400 Hz
sku98134 in stock
$1,800.00CAD
By Gertsch
<p>The Model DSRB combines the functions of a synchro bridge and a high resolution resolver bridge into a single unit. A front panel switch changes the unit from one mode of operation to the other. </p><p>The DSRB-5CD-4R Decade Synchro/ Resolver Bridge works in two ways: In resolver mode…
Description
<p>The Model DSRB combines the functions of a synchro bridge and a high resolution resolver bridge into a single unit. A front panel switch changes the unit from one mode of operation to the other. </p><p>The DSRB-5CD-4R Decade Synchro/ Resolver Bridge works in two ways:
In resolver mode, the resolver bridge uses precision transformers to form a voltage comparator bridge.
In synchro mode, the three wire input is converted to two voltage signals in a Scott-tee transformer arrangement.</p><ul><li>Frequency: 400 Hz</li><li> 2 seconds-of-arc accuracy</li><li>Angular range: 0....360°</li><li>Angular increments: 0.0001°</li><li>Full 360° rotation with direct angular readout 0.0001° resolution</li><li>Isolated and shielded input and output</li><li>Unity transformation ratio</li><li>Constant error voltage gradient</li><li>Both synchro and resolver input terminals</li><li>Front and rear 5-way binding posts</li><li>All terminals color-coded per Mil-Spec</li></ul><p>Additional specifications available upon request.</p>
In resolver mode, the resolver bridge uses precision transformers to form a voltage comparator bridge.
In synchro mode, the three wire input is converted to two voltage signals in a Scott-tee transformer arrangement.</p><ul><li>Frequency: 400 Hz</li><li> 2 seconds-of-arc accuracy</li><li>Angular range: 0....360°</li><li>Angular increments: 0.0001°</li><li>Full 360° rotation with direct angular readout 0.0001° resolution</li><li>Isolated and shielded input and output</li><li>Unity transformation ratio</li><li>Constant error voltage gradient</li><li>Both synchro and resolver input terminals</li><li>Front and rear 5-way binding posts</li><li>All terminals color-coded per Mil-Spec</li></ul><p>Additional specifications available upon request.</p>
