Product Description
Daughtercard with VHDM-HSD wafers ONLY; sequentially assigned custom part numbers.
VHDM-HSD systems provide enhanced electrical performance for differential signaling. These advantages include reduced in-pair skew, reduced cross talk and easier trace routing. Ground planes between signal columns provide tightly controlled impedance for rise times down to 50 picoseconds (10 - 90%), ensuring very low cross talk between signals within and between columns. The DAUGHTERCARD card connector consists of a metal stiffener, as in the VHDM** system, combining the signal wafers, power modules and guidance modules into one continuous connector that can be ordered as a single specific part number. These 2.00mm by 2.25mm pitch connectors have real signal density of 10 differential pairs and added flexibility of 15.00mm (.591) minimum distance between daughtercards. "
VHDM-HSD systems provide enhanced electrical performance for differential signaling. These advantages include reduced in-pair skew, reduced cross talk and easier trace routing. Ground planes between signal columns provide tightly controlled impedance for rise times down to 50 picoseconds (10 - 90%), ensuring very low cross talk between signals within and between columns. The DAUGHTERCARD card connector consists of a metal stiffener, as in the VHDM** system, combining the signal wafers, power modules and guidance modules into one continuous connector that can be ordered as a single specific part number. These 2.00mm by 2.25mm pitch connectors have real signal density of 10 differential pairs and added flexibility of 15.00mm (.591) minimum distance between daughtercards. "
