|  | HP 0960-2076 / Agilent 0960-2076 PIN Absorptive Modulator, 3 SMA Connectors
Call for price Please visit: www.torontosurplus.com for further details.
1 in stock
Call for price
|
| (Photo shy) |
HP 11710 / Agilent 11710 Down Converter
Please visit: www.torontosurplus.com for further details.
Available, photo and details to follow.
|
|  | HP 200CD / Agilent 200CD Wide Range Oscillator
Please visit: www.torontosurplus.com for further details.
Frequency Range: 5 Hz to 600 kHz.
Number of Ranges: 5 overlapping.
Output Voltage: 600 ohm load - 10 V rms (>160 mW), open circuit - 20 V rms.
Attenuator: continuously variable.
The body color & face plate color may be different from the photo and the leather handles are missing. They are in overall fair cosmetic condition.
Brownish older version $95.00 US As-is, Untested
Grey more recent version $ 125.00 US As-is, Untested
|
|  | HP 200CDR / Agilent 200CDR Wide Range Tube-Type Oscillator
$ 85.00 US As-Is Please visit: www.torontosurplus.com for further details.
This tube-type oscillator can produce a 5 Hz to 600 kHz sinewave. It has 5 ranges. 10 Volts maximum output into 600 Ohms and is a rackmount version.
$ 85.00 US As-Is
|
|  | HP 204C/002 / Agilent 204C/002 - Oscillator
Please visit: www.torontosurplus.com for further details.
The 204C is a versatile and easy-to-use instrument that covers the frequency range 5 Hz to 1.2 MHz in six overlapping ranges. The output attenuator i scontinuously variable, <40 dB range. It features low-distortion, sinusoidal output waveform.
Opt. 002 - Operation from AC line.
|
|  | HP 204D / Agilent 204D Oscillator
$ 225.00 US Please visit: www.torontosurplus.com for further details.
The 204D is a versatile and easy-to-use instrument that covers the frequency range 5 Hz to 1.2 MHz in six overlapping ranges. The output attenuator has a range of 80dB in 10dB steps. It features low-distortion, sinusoidal output waveform.
$ 225.00 US
|
|  | HP 214A / Agilent 214A Pulse Generator
$ 1150.00 US Please visit: www.torontosurplus.com for further details.
The 214A High-Power Pulse Generator is well-proven and easy to use. With a wide range of amplitude (0.08 V to 100 V), source impedance is 50-ohms on 50 V and lower ranges; ~1500-ohms on the 100 V range. Internal Repetition rate from 10Hz to 1MHz (5 ranges) and External from DC to 1MHz, 15 ns transition time on the +50 V range. Some of the features include pulse delay/advance with vernier, positive or negative polarity, trigger input, trigger output, gate input, and manual trigger mode.
$ 1150.00 US
|
| (Photo shy) |
HP 33001D / Agilent 33001D PIN Absorptive Modulator
Please visit: www.torontosurplus.com for further details.
Available, photo and details to follow.
|
|  | HP 3730B / Agilent 3730B OPT 010 Down Converter Mainframe, RF-IF Down Conversion (3737B plug in sold separately, below)
Call for price Please visit: www.torontosurplus.com for further details.
The 3730B Down Converter and plug-in RF modules (sold separately) provide RF to IF conversion and RF test capabilities for Microwave Link Analyzers (MLA's). The 0.7 to 14.5GHz RF range of the 3730B is accommodated by a series of local oscillator plug-ins, allowing easy tuning to the desired operating frequency. The 3730B has dual IF capability which allows the Down Converter to interface with single 70MHz IF or dual 70/140 MHz IF MLAs, or with wideband demodulators when white noise loading. A tracking AFC and recovered sweep facility causes the local oscillator in the 3730B to track the incoming swept RF signal, thus almost eliminating the swept component of the IF signal. This feature is particularly useful in wideband applications. It allows the Down Converter to be used in conjunction with an Up Converter and a conventional MLA to perform RF to RF measurements over bandwidths of up to 250 MHz.
FEATURES:
- RF to IF Frequency Conversion
- 1.7 to 14.5 GHZ Frequency Range (depending on plug-in used)
- Extends test capability of 70 or 140 MHz Output
- OPT 010: 25 dB Fixed Gain Amplifier, with 30 dB (10 dB step) Attenuator
Call for price
|
|  | HP 3737B / Agilent 3737B RF Module 3.7-8.5 GHz for use with 3730B Down Converter
Call for price Please visit: www.torontosurplus.com for further details.
Call for price
|
|  | HP 8003A / Agilent 8003A Pulse Generator
$ 375.00 US Please visit: www.torontosurplus.com for further details.
Repeat rate: to10 MHZ
Output +/- 5V into 50 OHMS
Risetime 5 nS
Variable width
$ 375.00 US
|
|  | HP 8004A / Agilent 8004A Pulse Generator
MIA or SOLD $ 250.00 US Please visit: www.torontosurplus.com for further details.
MIA or SOLD $ 250.00 US
|
|  | HP 8011A / Agilent 8011A Pulse Generator
$ 375.00 US Please visit: www.torontosurplus.com for further details.
The 8011A is a versatile, reliable pulse generator. This compact instrument features an uncomplicated design, using high quality components to ensure long, dependable service. Ease of operation results from the logical and simple front panel layout.
These qualities and the many pulse formats available emphasize this model's cost-effectiveness in a wide application range.
SPECIFICATIONS (50 ohm source/load):
- Transition times: < 10 ns fixed
- Overshoot, ringing and preshoot: < ±5% of pulse amplitude, May increase to 10% at counter-clock wise positions of amplitude vernier
- Pulse width: 25 ns to 100 ms in four ranges. Vernier provides continuous adjustment within each range
- Repetition Rate and Trigger 0.1 Hz to 20 MHz in 5 ranges. Vernier provides continuous adjustment within each range.
Made in Germany
$ 375.00 US
|
|  | HP 8012B / Agilent 8012B Pulse Generator, 50 MHz
$ 950.00 US Please visit: www.torontosurplus.com for further details.
1Hz-50MHz. Independent rise and fall times from 5ns to 0.5s, +/- 10V amplitude. Selectable source impedance, pulse delay, trigger, and gate inputs.
$ 950.00 US
|
|  | HP 8013A / Agilent 8013A Pulse Generator
Call for price Please visit: www.torontosurplus.com for further details.
This pulse Generator features two outputs of opposite polarity.
Pulse width is adjustable from less than 10 ns to 1 s.
Repetition rate is adjustable from 1Hz to 50MHz.
Pulse delay can be set from less than 35 ns to 1 s.
Call for price
|
|  | HP 8015A / Agilent 8015A - 50MHz Pulse Generator
$ 1500.00 US Please visit: www.torontosurplus.com for further details.
$ 1500.00 US
|
| (Photo shy) |
HP 8018A / Agilent 8018A Serial Data Generator, 50 MHz Serial Data / PRBS Generator
Call for price Please visit: www.torontosurplus.com for further details.
With 2048 programmable bits, and a choice of pseudo-random binary sequences (prbs) ranging to over 1 Mbits, the 8018A Serial Data Generator is a powerful stimulator for serial digital systems and devices requiring high bit rate and fast pulses. Even preamble-data-post-amble data link patterns are feasible by combining prbs and programmed data. Useful synch outputs simplify testing by locking scope or analyzer to unique points in the data stream.
For dual-channel applications, the memory splits so that the outputs have independent 1 Kbits of data. High performance output amplifier delivers clean, 6 ns pulses with repetition rates from DC to 50 Mbits/s. Output amplitude is variable up to 15 V into 50 ohms enabling the 8018A to directly drive logic circuits ranging from TTL to CMOS. Output levels for ECL are also provided.
Complete specifications available upon request.
Call for price
|
|  | HP 8112A / Agilent 8112A Pulse/Function Generator, 50 MHz with HPIB
Call for price Please visit: www.torontosurplus.com for further details.
The 8112A is fully programmable 50 MHz pulse generator with 5 ns transitions and 32 Vpp (into open circuit) max output amplitude. All pulse parameters are variable including delay and double pulse
spacing. Besides the comprehensive trigger modes, external moulation capabilitiess extend applicability, 3-level signals and upper level, width, period and delay-modulated signals are available. These can be combined with the trigger modes so that complex real-life signals like modulated
bursts are simulated easily.
SPECIFICATIONS:
- Timing:
Period & Double Pulse: 20.0 ns to 950 ms min
Delay: 65.0 ns to 950 ms min
Width: 10.0 ns to 950 ms min
- Accuracy: ± 5% of progr value ± 2 ns (delay:
±4 ns)
- Duty Cycle: 1% to 99%
Made in Germany
Additional specifications available upon request
Call for price
|
|  | HP 8180B / Agilent 8180B Data Generator, Opt 002
$ 2300.00 US Please visit: www.torontosurplus.com for further details.
This modular, high speed Data Generator provides input data for digital IC's and boards. Its features include a 50 MBit/s datarate, 16384 bit/channel on 8 parallel channels (including RZ/NRZ, Strobe and Clock), 50 ohm source impendance and an HP-IB interface.
Our unit is in BRAND NEW condition with 3 HP-15423A probes, a HP-15422A probe, cables and 20 HP 15426A Soldering receptacles.
$ 2300.00 US
|
|  | HP 8340B / Agilent 8340B Synthesized Sweep Generator OPT 005/006/007 10 MHz, 26.5 GHz Compatible with 8510A, 8515A
Call for price Please visit: www.torontosurplus.com for further details.
The 8340B delivers the combined high perfomance of a Synthesizer and Broadband Sweep Oscillator in one instrument that is completely controllable via HPIB.
FEATURES:
1-4 Hz Frequency ResolutionLow Spurious and Phase Noise100 ns Leveled Pulse Width Capability+10 dBm to -100 dBm Calibrated Output Complete Analog Sweeper DC to 100 kHz Amplitude Modulation
Complete specifications available upon request.
OPT 005 = Rear RF Panel Output without Attenuator
OPT 006 = Delete Pulse Modulation
OPT 007 = Relaxed Phase Noise Specifications
Call for price
|
|  | HP 8350A / Agilent 8350A Sweep Generator with HP 83570A RF Plug-In 18-26.5 GHz & HPIB
Call for price Please visit: www.torontosurplus.com for further details.
Sweep Oscillator applications are greatly expanded by the features of the 8350A. Along with the traditional Swept and CW frequency functions the 8350A adds five markers with extensive capabilities, versatile data entry and complete HP-IB programmability. The mainframe accepts the 86200 series plug-ins via the 11869A adapter (NOT included, as well as the 83500 series plug-ins which do not need the adapter.
The 8350A is the earlier version of the 8350B, and is compatible with the 8410C and 8755C Network Analyzers.
The 83570A RF Plug-in is also compatible with 8350B.
FEATURES:
- Accurate, high resolution digital displays
- Five markers with Marker Delta and Marker Sweep
- Save/Recall 9 complete front panel states
- Accepts 83500 series plug-ins
- HP-IB programmability Expands capabilities of sweep oscillator applicationa
- Frequency range depends on plug-in used
Complete specifications available upon request.
Call for price
|
|  | HP 8350B / Agilent 8350B Sweep Generator with HP 83545A RF Plug-In
$ 4995.00 US Please visit: www.torontosurplus.com for further details.
The HP 8350B is a powerful general purpose source for swept microwave measurements, wideband CW signal generation and automatic testing.
FEATURES
Extensive marker capabilities, Versatile data entry & complete HP-IB programmability, 10 MHz - 40 GHz from single plug-in (with the appropriate plug-in) , 10 mW output power to 26.5 GHz, Three methods of changing function values, Five markers making accurate location of important frequency responses easy.
The HP 83545A RF is a single-band plug-in with a Frequency Range of 5.9 GHz - 12.4 GHz (also compatible with 8350A)
This unit is in Mint condition.
$ 4995.00 US
|
|  | HP 83640A / Agilent 83640A Synthesized Sweeper / Sweep Generator 10 MHz to 40 GHz
Call for price Please visit: www.torontosurplus.com for further details.
The Agilent 83640A synthesized sweeper is the standard of excellence for applications requiring the high performance and accuracy of a synthesized source and the speed and versatility of a sweep oscillator. It delivers excellent harmonic performance with harmonics at least 50 dB below the carrier from 2.0 to 26.5 GHz, and at least 40 dB below the carrier above 26.5 GHz.
FEATURES:
- Scan modulation to simulate antenna scan patterns
- Accurate fixed and swept frequency offset for two-tone measurement
- User flatness correction for leveling at remote points in the test system
- General purpose source for use in component test, receiver test and for frequency conversion
- Frequency range: 10 MHz to 40 GHz
- Sweep modes: Step, List, Ramp
- Maximum power: < 26.5 GHz: +10 dBm
- Maximum power: > 26.5 GHz: +6.0 dBm
- Power sweep range: -20 dBm to maximum power
- Phase noise (38 GHz at 10 KHz): -70 dBc
- Max FM deviation (locked): +/- 8 MHz
Specifications available upon request.
Call for price
|
|  | HP 8614A / Agilent 8614A Signal Generator, UHF
$ 325.00 US Please visit: www.torontosurplus.com for further details.
Covers the 800 MHz to 2400 MHz range with RF output power of + 10 dBm to -127 dBm (into 50 Ohms load). Frequency and attenuation are set on direct-reading dials. Functions include CW, leveled output, square wave modulation, and external AM, FM, and pulse modulation.
$ 325.00 US
|
|  | HP 8616A / Agilent 8616A Signal Generator
$ 850.00 US Please visit: www.torontosurplus.com for further details.
SPECIFICATIONS:
- Frequency Range: 1800 to 4500 MHz.
- Amplitude Modulation: DC to 1 MHz.
- RF Pulses: 2 uS rise time.
- Selectable Functions: CW, leveled output, square-wave modulation, external AM, FM, and pulse modulation
Two RF power outputs are available. One provides at least 10 mW below 3000 MHz and 2 mW above, or a leveled output from 0 to -127 dBm. The other is at least 0.5 mW.
$ 850.00 US
|
|  | HP 8620B / Agilent 8620B Sweep Oscillator with 86220A RF Plug In 10 - 1300 MHz
Call for price Please visit: www.torontosurplus.com for further details.
The front is scratched, but it Works!
1 in stock
Call for price
|
|  | HP 8640B / Agilent 8640B RF Signal Generator, 500 kHz to 512 MHz Opt 1, 3, 1/3, 1/2/3
Please visit: www.torontosurplus.com for further details.
This very popular generator covers a frequency range of 500 kHz to 512 MHz (512-1024 MHz requires external doubler) with a levelled output range of -145 dBm to +19 dBm (0.013 microV to 2V). Versatile AM, FM and pulse modulation. Phase lock and an internal 6-digit counter eliminates the need for a separate frequency counter. The 8640's superb spectral purity and low phase noise is due to its sophisticated cavity oscillator design.
AVAILABLE OPTIONS:
Opt 1 (20 Hz - 600 kHz Internal Audio Oscillator),
Opt 2 (Internal Frequency Doubler 512-1024 MHz) and
Opt 3 (Reverse Power Protection).
PRICING:
8640B Opt 1 only - $ 949.00 US
8640B Opt 3 only - $ 1000.00 US
8640B Opt 1/3 - $ 1100.00 US
8640B Opt 1/2/3 - $1750.00 US
|
|  | HP 8642B / Agilent 8642B Signal Generator 0.1 - 2100 MHz, Option 001
$ 7000.00 US Please visit: www.torontosurplus.com for further details.
This is the Hewlett-Packard 8642B Signal Generator. This is a high performance programmable signal generator that is intended to operate with even the most demanding RF applications. Frequancy range from 100 kHz to 2115 MHz. The Option 001 is a factory installed high stability time base.
$ 7000.00 US
|
|  | HP 8645A / Agilent 8645A Agile Signal Generator 0.26-1030 MHz
Call for price Please visit: www.torontosurplus.com for further details.
The 8645A Agile Signal Generator provides specified signal performance in both static and agile operation. Fully-synthesized outputs with high timebase accuracy are standard when not frequency hopping. The Fast Hop mode activates a frequency-lock loop to allow frequency switching as fast as 15 µs from 128 to 1030 MHz. Over the frequency range of 8 to 1030 MHz, the fastest switching time is 85 µ and outputs below 8 MHz require 500 µs.
FEATURES:
- 252 kHz - 1030 MHz Frequency Range
- 15 µs Frequency Switching
- Standalone Control of Frequency Agility
- Specified Performance While Fast Hopping
- FM Rates to 10 MHz, Deviations to 20 MHz
- Low Spurious and Phase Noise
Additional specifications available upon request.
Call for price
|
|  | HP 8654A / Agilent 8654A Signal Generator, 10 to 520MHz in 6 bands
Call for price Please visit: www.torontosurplus.com for further details.
Call for price
|
| (Photo shy) |
HP 8656A / Agilent 8656A / 001 Signal Generator, 100kHz - 990MHz
Call for price Please visit: www.torontosurplus.com for further details.
FEATURES / SPECIFICATIONS:
- Frequency Range: 100 kHz to 990 MHz
- Resolution: 100 or 250 Hz
- Output Levels: -127 dBm to +13 dBm
- Internal modulation (2-digit display): 400 and 1000 Hz, AM, FM or combo
- HP-IB Programmable
- Opt 001 = High Stability Time Base
Call for price
|
|  | HP 8656B / Agilent 8656B Signal Generator. 100kHz - 990MHz
Call for price Please visit: www.torontosurplus.com for further details.
AM and FM modulation
SPECIFICATIONS:
- Frequency Range: 100 kHz - 990 MHz
- Frequency Resolution: 10 Hz
- Output Accuracy: + 1.0 dB
- Output Range: -127 dBm to + 13 dBm
- Output Resolution: .1 dB
- SSB Phase Noise Range: -126 dBc to -114 dBc
Call for price
|
| (Photo shy) |
HP 8657A / Agilent 8657A Signal Generator, 100 kHz-1040 MHz OPT 002
$1595.00 Please visit: www.torontosurplus.com for further details.
AM and FM modulation, Low SSB phase noise, Amplitude offset and phase adjust.
OPT 002 = RF Connectors on Rear Panel Only
$1595.00
|
|  | HP 8660C / Agilent 8660C Synthesized Signal Generator, 1MHz - 2.6 GHz OPT 005, 100, 003
Call for price - Please specify unit Please visit: www.torontosurplus.com for further details.
The 8660C Synthesized Signal Generator mainframe provides direct keyboard entry of CW frequencies. The mainframe offers digital sweep, frequency stepping, control of frequency with a tuning knob, and a ten-digit numerical display. Auto, Single, or manual digital sweep with selectable speeds of 0.1, 1, or 50 seconds.
This mainframe utilizes the 866xx series of plug-ins which you will find on our "test, plug-ins" page.
Pictured is model 8660B, but 'C' looks the same.
2 IN STOCK:
1) OPT 005: HP-IB programming interface (cables not supplied), and OPT 100: HP 11661B Frequency Extension Module (required for RF modules up to 1300 and 2600MHz).
2) OPT 001: ±3 x 10E-09/day internal reference oscillator, and OPT 003: Operation from 50 to 400Hz line
Call for price - Please specify unit
|
|  | HP 8660D / Agilent 8660D Synthesized Signal Generator, w/ 86632A & 86603A, w/ options 005 & 100
$ 1750.00 US Please visit: www.torontosurplus.com for further details.
This is a Hewlett-Packard HP 8660D Synthesized Signal Generator. Included in this mainframe are the HP 86632A Modulation Section and the HP 86603A RF Section. This Signal Generator has two HP options:
Option 005- factory configured for HP-IB programming operation.
Option 100- HP 11661B Frequency Extension Module (required for RF modules up to 1300 and 2600MHz).
$ 1750.00 US
|
|  | HP 8663A / Agilent 8663A Synthesized Signal Generator 100kHz - 2560MHz, Option 002 & 003
$ 13450.00 US Please visit: www.torontosurplus.com for further details.
This is a Hewlett-Packard 8663A Synthesized Signal Generator. It has a frequancy range up to 2560 MHz and an output level of up to +16 dBm with the addition of phase and modulation. This
unit has two options added:
Option 002 is a wideband linear phase modulation.
Option 003 is a specified SSB phase noise for 640 MHz output
SPECIFICATIONS:
- Frequancy range from 100 kHz to 2560MHz
- Output range of +16 dBm to -129.9 dBm
- high spectral purity
- standard HP-IB interface
$ 13450.00 US
|
|  | HP 8672A / Agilent 8672A Synthesized Signal Generator 2-18 GHz
$ 5500.00 US Please visit: www.torontosurplus.com for further details.
$ 5500.00 US
|
| (Photo shy) |
HP 8690A / Agilent 8690A Sweep Oscillator
$ 475.00 US Please visit: www.torontosurplus.com for further details.
Looks identical to the B version below
$ 475.00 US
|
|  | HP 8690B / Agilent 8690B Sweep Oscillator
$ 500.00 US mainframe only. Please visit: www.torontosurplus.com for further details.
The base model doesn't turn you on? Check out our list of plug-ins for this unit in the HP/Tek PlugIn Section!!
$ 500.00 US mainframe only.
|
